Contact to Cable - 1 Thermocouple Wire Pair

0 Review(s)

One pair (Type-K) of Kapton® Insulated Chromel® and Alumel® Wires with Chromel® and Alumel® Sockets (Female) on one end.

Options of 19" or 39" inches are available here.  Custom lengths are also available, please call.



Part Number:
100850
Stock Level:
in stock
Weight (lbs):
0.10

$52.00

Specifications

Materials:
Kapton, Chromel, Alumel
RoHS Compliant:
Yes
Max. Bake Temperature:
250ºC
Max. Operating Temperature:
250ºC
Max. Vacuum Level:
1x10E-10 Torr
Current rating:
TC Pins - Milliamps
Number Contacts:
1-TC pair
Gender:
Female
Contact Material:
Chromel, Alumel
Other Information:

Thermocouple feedthroughs do not measure temperature, but merely provide a conduit to bring the EMF signal generated at a thermocouple junction through a vacuum vessel wall to an external voltage measuring or temperature readout instrument. Type-K thermocouples with positive Chromel wires and negative Alumel wires are recommended for use in clean oxidizing atmospheres. The maximum operating temperature for these alloys is 1260 C for larger wire sizes. The useful temperature measuring range for a Type-K thermocouple is between (-)200 C to (+)1250 C.
