HV PCB Connector - 25 Pin - Male
25 Pin (Male), High Vacuum Printed Circuit Board (PCB) mount subminiature-D connector.
Part Number:
111102 Weight: 0.1 lbs
$180.00
(661) 607-0250
Custom Solutions
Categories
Custom Solutions
Categories
Home › HV PCB Connector - 25 Pin - Male
- Specifications
- Downloads
- Detailed Images
| Model Number: | 25D-HVPCBP |
| Materials: | DAP, SS |
| RoHS Compliant: | Yes |
| Max. Bake Temperature: | 120ºC |
| Max. Operating Temperature: | 120ºC |
| Max. Vacuum Level: | 1x10E-8 Torr |
| Number Contacts: | 25 |
| Gender: | Male |
