50-Pin Male High Vacuum Printed Circuit Board (PCB) Connector

HV PCB Connector - 50 Pin - Male

50 Pin (Male), High Vacuum Printed Circuit Board (PCB) mount subminiature-D connector.

Part Number:
112657
Weight: 0.01 lbs
$268.00
  • Specifications
  • Downloads
  • Detailed Images
Model Number:50D-HVPCBP
Materials:DAP, SS
RoHS Compliant:Yes
Max. Bake Temperature:120ºC
Max. Operating Temperature:120ºC
Max. Vacuum Level:1x10E-8 Torr
Number Contacts:50
Gender:Male
