15 Way, Kapton Insulated - Ribbon Cable
15 Way Kapton Ribbon Cable.
19", 39", and 96"ย lengths. ย Custom lengths are also available, please call.
Part Number:
100750 Weight: 0.1 lbs
$79.00
Home โบ Wire and Cable โบ UHV / Kaptonยฎ Insulated โบ Ribbon Cable โบ 15 Way, Kapton Insulated Ribbon Cable
- Specifications
- Detailed Images
| Model Number: | KAP-R15-19" or KAP-R15-39" or KAP-R15-96" |
| Materials: | Kapton, Ag-plt Cu |
| RoHS Compliant: | Yes |
| Max. Bake Temperature: | 250ยบC |
| Max. Operating Temperature: | 250ยบC |
| Max. Vacuum Level: | 1x10E-10 Torr |
| Wire Gauge: | 28 AWG |
| Voltage rating: | 600VAC, 2kVDC |
| Current rating: | 2 AMP |
| Resistance: | 244.0 ฮฉ/km at 20ยบC max. |
| Minimum Bend Radius, Long-Term: | 0.53" |
