UHV Connector - Panel Mount 50D Connector

UHV Connector - Panel Mount 50D Connector

UHV Connector - Panel Mount 50D Connector

1 Review(s)

50 pin Male, PEEK sub-D panel mount connector with mounting ears. (Pins sold separately and are in picture as an example only)
Part Number:
100431
Stock Level:
in stock
Weight (lbs):
0.1

$299.00

Specifications

Model Number:
50D-PKP-E
Materials:
PEEK, SS
RoHS Compliant:
Yes
Max. Bake Temperature:
250ºC
Max. Operating Temperature:
250ºC
Max. Vacuum Level:
1x10E-10 Torr
Number Contacts:
50, not included
Gender:
Male

Detailed images

50D Subminiature-D Panel Mount Machining Detail

Downloads
