UHV Connector - Panel Mount 9D Connector

UHV Connector - Panel Mount 9D Connector

UHV Connector - Panel Mount 9D Connector

0 Review(s)

9 pin Male, PEEK sub-D panel mount connector with mounting ears.

(Contacts in picture not included)
Part Number:
112125
Stock Level:
in stock
Weight (lbs):
0.1

$177.00

Specifications

Model Number:
9D-PKP-E
Materials:
PEEK, SS
RoHS Compliant:
Yes
Max. Bake Temperature:
250ºC
Max. Operating Temperature:
250ºC
Max. Vacuum Level:
1x10E-10 Torr
Number Contacts:
9, not included
Gender:
Male

Detailed images

9D Subminiature-D Panel Mount Machining Detail
