Viewport, Corning 7056 glass, 1.40" view diameter, mounted on a 2.75" CF flange.
Optional AR Coatings :
NB1 Narrow Band for 780nm
NB2 Narrow Band for 1064nm
| Larson Electronic Glass - Part Number: | 111162 |
| Larson Electronic Glass - Model Number: | VP-150-F2 |
| Model Number: | VPG-1.4-275 |
| Materials: | Corning 7056 glass, SS |
| RoHS Compliant: | Yes |
| Max. Bake Temperature: | 250ºC |
| Max. Operating Temperature: | 250ºC |
| Max. Vacuum Level: | 1x10E-10 Torr |
2.75" CF Conflat® CF flange, OFHC copper gaskets, 1.45 ID.
10 per package.
2.75" CF flange, OFHC copper, 1.53 Internal Dimension. Larger "Internal Dimension" for use with flange that may have multiple feedthroughs. Used for extra clearance.
10 per package.
