Corning 7056 Glass Viewport - NW80 LF Flange

Corning 7056 Glass Viewport - NW80 LF Flange

Corning 7056 Glass Viewport - NW80 LF Flange

0 Review(s)

Viewport, Corning 7056 glass, 1.40" view diameter, mounted on an NW80 LF flange.

Part Number:
112448
Stock Level:
in stock
Weight (lbs):
1.50
$275.00

Specifications

Model Number:
VPG-1.4-L80
Materials:
Corning 7056 Glass, SS, and Kovar
RoHS Compliant:
Yes
Max. Bake Temperature:
150ºC
Max. Operating Temperature:
150ºC
Thermal Gradient:
20ºC / Minute (Maximum)
Larson Electronic Glass - Part Number:
111168
Larson Electronic Glass - Model Number:
VP-150-L8

Detailed images

Corning 7056 Borosilicate Glass Viewport - 1.33" CF Flange

Downloads

112448.pdf
112448.zip
112448.eprt
