SMA - Double Ended, Floating Shield Feedthrough on a 2.75" CF Flange
SMA - Double Ended, Floating Shield Coaxial Feedthrough on a 2.75" CF Flange.
Part Number:
110758 Weight: 0.75 lbs
$938.00
(661) 607-0250
Custom Solutions
Categories
Custom Solutions
Categories
Home › 2SMA-FS-275
- Specifications
- Downloads
- Detailed Images
| Model Number: | 2SMA-FS-275 |
| Materials: | SS, Glass-Ceramic |
| RoHS Compliant: | Yes |
| Max. Bake Temperature: | 250ºC |
| Max. Operating Temperature: | 250ºC |
| Max. Vacuum Level: | 1x10E-10 Torr |
| Current rating: | 1 AMP |
| Number Contacts: | 1 |
| Gender: | Air: SMA female / Vacuum: SMA female |
| Contact Material: | SS, Ni-plt |
