Connector to Cable - 1 Coax, 4 Instrumentation - Female

Connector to Cable - 1 Coax, 4 Instrumentation, Female

Connector to Cable - 1 Coax, 4 Instrumentation, Female

0 Review(s)

1 Kapton Coaxial Cable (26AWG, 50 Ohm) + 4 Single Way Kapton Cables with Sockets (Female) & a Peek D-Type Connector on one end and "Connector #2" option on the other.

Options of 19" or 39" inches are available here. Custom lengths are also available, please call.

Part Number:
100620
Stock Level:
in stock
Weight (lbs):
0.10

$227.00

Specifications

Model Number:
9KAP-1CX4i-19SC or 9KAP-1CX4i-39SC
Materials:
Kapton®, PEEK
RoHS Compliant:
Yes
Max. Bake Temperature:
250ºC
Max. Operating Temperature:
250ºC
Max. Vacuum Level:
1x10E-10 Torr
Number Contacts:
1 - Coax, 4 - Instrumentation
Gender:
Female
Contact Material:
Ni-Fe alloy, Au-plt

Detailed images

Connector to Cable - 1 Coax, 4 Instrumentation, Female
