Contacts, Type-T1 Standard - Female (25 Pack)

.040 Diameter female socket, gold plated contacts / Wire-well accepts 20~24 AWG wire size / 25-Pack

For 26-30 AWG size (111501, sold separately) please change 'Wire Acceptance' selection below...

Part Number:

111500

Weight: 0.20 lbs

$75.00

Quantity

Wire Acceptance

Model Number:

GS-25 or GS2-25

Materials:

Copper alloy, Au-plt

RoHS Compliant:

Yes

Max. Bake Temperature:

250ºC

Max. Operating Temperature:

250ºC

Max. Vacuum Level:

1x10E-10 Torr

Current rating:

5 AMP

Number Contacts:

25 Per Package

Gender:

Female

Contact Material:

Copper alloy, Au-plt
