Step-Index, VIS/NIR Fiber Optic CF Feedthrough Flanges

100-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 1.33" CF Flange with Male SMA 905 Connectors on Each End

100 Single Fiber, 1.33 CF, VIS/NIR

Part Number: 112553

Fiber Optic Feedthrough (100 micron VIS/NIR), mounted on a 133" CF Flange.Male SMA 905 connectors on each end.

$840.00
100-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

100 Single Fiber, 2.75 CF, VIS/NIR

Part Number: 112554

Fiber Optic Feedthrough (100 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$857.00
Dual 100-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

100 Dual Fiber, 2.75 CF, VIS/NIR

Part Number: 112555

2ea. Fibre Optic Feedthrough (100 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$1,518.00
200-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 1.33" CF Flange with Male SMA 905 Connectors on Each End

200 Single Fiber, 1.33 CF, VIS/NIR

Part Number: 105020

Fiber Optic Feedthrough (200 micron VIS/NIR), mounted on a 133" CF Flange.Male SMA 905 connectors on each end.

$575.00
200-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

200 Single Fiber, 2.75 CF, VIS/NIR

Part Number: 105021

Fiber Optic Feedthrough (200 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$598.00
Dual 200-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

200 Dual Fiber, 2.75 CF, VIS/NIR

Part Number: 112308

2ea. Fibre Optic Feedthrough (200 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$1,047.00
Seven, 200-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with a Non-Threaded Female SMA Interface on Both Ends

200 Seven Fiber, 2.75 CF, VIS/NIR

Part Number: 112820

7ea. Fibre Optic feedthroughs sealed in a single body (200 micron VIS/NIR), mounted on a 275" CF Flange.

$3,393.00
400-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 1.33" CF Flange with Male SMA 905 Connectors on Each End

400 Single Fiber, 1.33 CF, VIS/NIR

Part Number: 105120

Fiber Optic Feedthrough (400 micron VIS/NIR), mounted on a 133" CF Flange.Male SMA 905 connectors on each end.

$587.00
400-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

400 Single Fiber, 2.75 CF, VIS/NIR

Part Number: 105121

Fiber Optic Feedthrough (400 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$604.00
Dual 400-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

400 Dual Fiber, 2.75 CF, VIS/NIR

Part Number: 112309

2ea. Fibre Optic Feedthrough (400 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$1,052.00
Seven, 400-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with a Non-Threaded Female SMA Interface on Both Ends

400 Seven Fiber, 2.75 CF, VIS/NIR

Part Number: 112821

7ea. Fibre Optic feedthroughs sealed in a single body (400 micron VIS/NIR), mounted on a 275" CF Flange.

$3,278.00
600-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 1.33" CF Flange with Male SMA 905 Connectors on Each End

600 Single Fiber, 1.33 CF, VIS/NIR

Part Number: 105220

Fiber Optic Feedthrough (600 micron VIS/NIR), mounted on a 133" CF Flange.Male SMA 905 connectors on each end.

$592.00
600-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

600 Single Fiber, 2.75 CF, VIS/NIR

Part Number: 105221

Fiber Optic Feedthrough (600 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$615.00
Dual 600-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

600 Dual Fiber, 2.75 CF, VIS/NIR

Part Number: 112310

2ea. Fibre Optic Feedthrough (600 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$1,058.00
Seven, 600-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with a Non-Threaded Female SMA Interface on Both Ends

600 Seven Fiber, 2.75 CF, VIS/NIR

Part Number: 112822

7ea. Fiber Optic feedthroughs sealed in a single body (600 micron VIS/NIR), mounted on a 275" CF Flange.

$3,163.00
Seven, 1000-Micron, VIS/NIR Fiber Optic Feedthrough Mounted on a 2.75" CF Flange with a Non-Threaded Female SMA Interface on Both Ends

1000 Seven Fiber, 2.75 CF, VIS/NIR

Part Number: 112823

7ea. Fiber Optic feedthroughs sealed in a single body (1000 micron VIS/NIR), mounted on a 275" CF Flange.

$3,048.00
1000-Micron, VIS/NIR Fiber Optic Feedthrough on a 1.33" CF Flange with Male SMA 905 Connectors on Each End

1000 Single Fiber, 1.33 CF, VIS/NIR

Part Number: 105320

Fiber Optic Feedthrough (1000 micron VIS/NIR), mounted on a 133" CF Flange.Male SMA 905 connectors on each end.

$667.00
1000-Micron, VIS/NIR Fiber Optic Feedthrough on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

1000 Single Fiber, 2.75 CF, VIS/NIR

Part Number: 105321

Fiber Optic Feedthrough (1000 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$673.00
Dual 1000-Micron, VIS/NIR Fiber Optic Feedthrough on a 2.75" CF Flange with Male SMA 905 Connectors on Each End

1000 Dual Fiber, 2.75 CF, VIS/NIR

Part Number: 112311

2ea. Fibre Optic Feedthrough (1000 micron VIS/NIR), mounted on a 275" CF Flange.Male SMA 905 connectors on each end.

$1,162.00

█ VIS/NIR Fiber Optic Feedthroughs on CF

Accu-Glass offers fiber optic feedthroughs with 62.5, 100, 200, 400, 600, and 1000 micron core diameters. These feedthroughs are ideally suited for industrial and/or scientific research applications requiring air-to-vacuum fiber optic transitions/connections. Multimode fibers (both Step and Graded Index types) are hermetically sealed into a stainless steel shell, using the latest in glass-ceramic-metal bonding technology. Standard fiber optic feedthroughs are terminated with premium SMA 905 connectors on both vacuum and air sides. FC and ST connections are also available.
Polyimide buffered optical fiber cable assemblies are offered to meet the rigorous demands of ultrahigh vacuum environments. These optical fibers are of a core-and-cladding composite construction. The core, or the filament that guides the light, consists of a thin strand of high-transmission fused silica. The cladding is an outer layer of doped, lower refractive-index fused silica. This dual-layer design tightly confines light to the fiber's central core, thus delivering the maximum amount of light possible at the fiber's destination. Fiber diameters are closely controlled during the drawing process, allowing fibers to center well in connectors and boast low loss rates.
Graded-index multimode fiber bridges the gap between single-mode and step-index multimode fibers, giving up some bandwidth for ease of termination and light launch. It's more economical than single-mode fiber, and primarily used for data communication (not as useful for power transmission) applications requiring medium run distances of 2 to 15 km lengths.

  • █ High-OH, 200-800nm UV/VIS
    For UV/VIS applications only. Use ≤ 15 meter lengths to avoid high attenuation.

  • █ Ultra Low-OH, 400–2200nm VIS/NIR
    For extremely long length VIS/NIR applications. Lowest possible light attenuation.


Atenuation Curves

Features

  • UHV compatible construction
  • 100, 200, 400, 600, and 1000μm
    UV, VIS and NIR Step Index fibers
  • 62.5μm NIR Graded Index fiber
  • SMA 905 premium connector interface
  • High temperature rated to 250°C
  • Conflat® and ISO KF compatible mounts
  • Polyimide buffered vacuum rated optical cables

Specifications

Material
Hardware, Stainless Steel304
Fiber Construction
   Core, SilicaSiO2
   Cladding, Fluorine-Doped SilicaF-SiO2
   Buffer, Aluminum (Feedthrough)Al
   Buffer, Polyimide (Cable)PI
Vacuum Range
UHV, Ultrahigh vacuum1x10E-10 Torr
HV, High vacuum1x10E-8 Torr
Temperature Range 1
Feedthrough-200 to 250°C
Flange, Conflat®-200 to 450°C
Flange, ISO150°C
Connector / Cable, Air80°C
Connector / Cable, UHV-65 to 200°C
Thermal Gradient, Maximum25°C/minute
Step Index Fiber 2
Operational Wavelengths
   █ UV / VIS, High-OH200-800 nm
   █ VIS / NIR, Ultra Low-OH400-2200 nm
Diameters, Five (5) Core100 to 1000 µm
Aperture, 24.8° Numerical0.22 ± 0.02
Core / Cladding Ratio 31 : 1.1
Power< 1W
Bend Radius 4200x
   Momentary200x
   Long Term400x
Insertion Loss 5, Interconnect-0.8 to -2.0 dB
Graded Index Fiber
Core Diameter62.5 µm
Clad Diameter125 µm
Operational Wavelengths 6, Two
   Optimized for use @850 nm
   Optimized for use @1300 nm
Aperture, Numerical0.27 ± 0.02
Bend Radius 4
   Momentary400x
   Long Term800x
Attenuation @ 850, and 1300 nm
   @ 850 nm≤ 3.0 dB
   @ 1,300 nm≤ 0.8 dB
Notes
  1. Overall assembly ratings must be adjusted to that of its lowest rated component. For cryogenic service, the lowest recommended temperature is -80°C
  2. Bare fiber has a pure fused-silica core, fluorine-doped silica cladding, and Polyimide buffer.
  3. Where core diameter is ≥ 200 µm
  4. Bend radius is expressed as this factor x the core diameter
  5. Dependent on wavelength and fiber size.
  6. Optimized for these two specific wavelengths
  7. Vacuum and air side connectors, cables and couplers are not included with feedthrough and must be purchased separately.
