2MHV-FS-K40

MHV - Double Ended, Floating Shield Feedthrough on a KF40 Flange

Share this:


MHV - Double Ended, Floating Shield Feedthrough on a KF40 Flange

1 Review(s)

MHV - Double Ended, Floating Shield Coaxial Feedthrough on a NW40 KF Flange.

Part Number:
110179
Stock Level:
in stock
Weight (lbs):
0.3

$432.00

Specifications

Model Number:
2MHV-FS-K40
Materials:
SS, Glass-Ceramic
RoHS Compliant:
Yes
Max. Bake Temperature:
200ºC
Max. Operating Temperature:
150ºC, limited by O-ring type used.
Max. Vacuum Level:
1x10E-8 Torr
Current rating:
3 AMP
Number Contacts:
1
Gender:
Air: MHV female / Vacuum: MHV female
Contact Material:
SS, Ni-plt
