Sapphire Viewport (RG) - 1.44 View on 2.75" CF Flange

Sapphire Viewport (RG) - 1.44"Ø, 2.75"CF

Viewport, Sapphire glass (Regular Grade), 1.44" view diameter, mounted on a 2.75" CF flange.

Part Number:
112725
Weight: 2.5 lbs
$843.00
  • Specifications
  • Downloads
  • Detailed Images
Model Number:VPS-1.5-275
Materials:Sapphire, SS
RoHS Compliant:Yes
Max. Bake Temperature:250ºC
Max. Operating Temperature:250ºC
Max. Vacuum Level:1x10E-10 Torr
Thermal Gradient:10°C/ Minute Maximum
