Sapphire Viewport (RG) - 1.94 View, 4.50" CF Flange

Sapphire Viewport (RG) - 1.94"Ø, 4.50"CF

Viewport, Sapphire glass (Regular Grade), 1.94" view diameter, mounted on a 4.50" CF flange.

Part Number:
112466
Weight: 2.5 lbs
$1,216.00
  • Specifications
  • Downloads
  • Detailed Images
Model Number:VPS-2-450
Materials:Sapphire, Kovar, 304SS
RoHS Compliant:Yes
Max. Bake Temperature:350ºC
Max. Operating Temperature:250ºC
Max. Vacuum Level:1x10E-10 Torr
Thermal Gradient:10°/Minute Maximum
