Sapphire Viewport (UV) - 1.33" CF Flange

Sapphire Viewport (UV) - 0.59 View on 1.33" CF Flange
Sapphire Viewport (UV) - 0.59 View on 1.33" CF Flange

Sapphire Viewport (UV) - 0.59"Ø, 1.33"CF

5 Review(s)

Viewport, Sapphire (UV Grade), 0.59" view diameter, mounted on a 1.33" CF flange with 3/4" Neck.

Part Number:
112415
Stock Level:
in stock
Weight (lbs):
0.25

$345.00

Specifications

Model Number:
VPS-0.6-133
Materials:
Sapphire, Kovar, 304SS
RoHS Compliant:
Yes
Max. Bake Temperature:
350ºC
Max. Operating Temperature:
250ºC
Max. Vacuum Level:
1x10E-10 Torr
Thermal Gradient:
10ºC/Minute Maximum
