Sapphire Viewport (UV) - 0.94"Ø, 2.75"CF
Viewport, Sapphire glass (UV Grade), 0.94" view diameter, mounted on a 2.75" CF flange.
Part Number:
112416 Weight: 1 lb
$425.00
(661) 607-0250
Custom Solutions
Categories
Home › Sapphire Viewport (UV) - 2.75" CF Flange
- Specifications
- Downloads
- Detailed Images
| Model Number | VPS-1-275 |
| Materials | Sapphire, SS |
| RoHS Compliant | Yes |
| Max. Bake Temperature | 250ºC |
| Max. Operating Temperature | 250ºC |
| Max. Vacuum Level | 1x10E-10 Torr |
| Thermal Gradient | 10ºC/Minute Maximum |
